Sport Glide^™

DESCRIPTION

Devour endless miles of highway. Lean hard through twisting roads. Hit the night spots. Adventure is yours for the taking on the Sport Glide^™.

DISCLAIMER

Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered. Availability may vary by market, please see your local dealer for details.

BOOK TEST RIDE

SPECIFICATION

DIMENSIONS

Length	2325 mm
Seat Height, Unladen	680 mm
Ground Clearance	120 mm
Rake (Steering Head) (Deg)	30
Trail	150 mm
Wheelbase	1625 mm
Tires, Front Specifications	130/70B18 63H BW
Tires, Rear Specification	180/70B16 77H BW
Fuel capacity	18.9 l
Oil Capacity (W/Filter)	4.7 l
Weight, as Shipped	304 kg
Weight, in Running Order	317 kg
Luggage Capacity - Volume	0.05 m³

ENGINE

Engine	Milwaukee-Eight^™ 107
Bore	100 mm
Stroke	111 mm
Displacement	1746 cm³
Compression Ratio	10.0:1
Fuel System	Electronic Sequential Port Fuel Injection (ESPFI)
Exhaust	2-into-1; catalyst in muffler

DRIVE TRAIN

Primary Drive (*Cert)	Chain, 34/46 ratio
Gear Ratio (Overall) 1^st (*Cert)	9.311
Gear Ratio (Overall) 2^nd (*Cert)	6.454
Gear Ratio (Overall) 3^rd (*Cert)	4.793
Gear Ratio (Overall) 4^th (*Cert)	3.882
Gear Ratio (Overall) 5^th (*Cert)	3.307
Gear Ratio (Overall) 6^th (*Cert)	2.79

PERFORMANCE

Engine Torque Testing Method	EC 134/2014
Engine Torque (*Cert)	139 Nm
Engine Torque (RPM)	3500
Lean Angle, Right (Deg.)	27.9
Lean Angle, Left (Deg.)	28.7

CHASSIS

Wheels, Front Type	Black, machine highlighted, Mantis cast aluminum
Wheels, Rear Type	Black, machine highlighted, Mantis cast aluminum
Brakes, Caliper Type	4-piston fixed front and 2-piston floating rear

ELECTRIC

Lights (As per country regulation), Indicator Lamps	High beam, turn signals, neutral, low oil pressure, engine diagnostics, cruise, ABS, security, low battery voltage, low fuel
Gauges	5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
