IRON 883^™

DESCRIPTION

An original icon of the Harley-Davidson^® Dark Custom style. It sets the standard for the raw, stripped-down, blacked-out look.

DISCLAIMER

Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered. Availability may vary by market, please see your local dealer for details.

BOOK TEST RIDE

SPECIFICATION

DIMENSIONS

Length	2185 mm
Seat Height, Unladen	760 mm
Ground Clearance	140 mm
Rake (Steering Head) (Deg)	30
Trail	117 mm
Wheelbase	1515 mm
Tires, Front Specifications	100/90B19 57H
Tires, Rear Specification	150/80B16 77H
Fuel capacity	12.5 l
Oil Capacity (W/Filter)	2.6 l
Weight, as Shipped	247 kg
Weight, in Running Order	256 kg

ENGINE

Engine	Air-cooled, Evolution^™
Bore	76.2 mm
Stroke	96.8 mm
Displacement	883 cm³
Compression Ratio	9:01
Fuel System	Electronic Sequential Port Fuel Injection (ESPFI)
Exhaust	Black exhaust headers and black mufflers

DRIVE TRAIN

Primary Drive (*Cert)	Chain, 38/57 ratio
Gear Ratio (Overall) 1^st (*Cert)	9.315
Gear Ratio (Overall) 2^nd (*Cert)	6.653
Gear Ratio (Overall) 3^rd (*Cert)	4.948
Gear Ratio (Overall) 4^th (*Cert)	4.102
Gear Ratio (Overall) 5^th (*Cert)	3.517

PERFORMANCE

Engine Torque Testing Method	EC 134/2014
Engine Torque (*Cert)	68 Nm
Engine Torque (RPM)	4750
Lean Angle, Right (Deg.)	27
Lean Angle, Left (Deg.)	28

CHASSIS

Wheels, Front Type	Black 9 Spoke with Machined Highlights
Wheels, Rear Type	Black 9 Spoke with Machined Highlights
Brakes, Caliper Type	Dual-piston front, Dual-piston rear

ELECTRIC

Lights (As per country regulation), Indicator Lamps	High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
Gauges	Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
