FORTY-EIGHT^™

DESCRIPTION

Heavy-hitting style with fat tires and an iconic peanut tank. Designed with its signature bulldog stance and 1200cc of corner cranking torque.

DISCLAIMER

Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered. Availability may vary by market, please see your local dealer for details.

BOOK TEST RIDE

SPECIFICATION

DIMENSIONS

Length	2165 mm
Seat Height, Unladen	710 mm
Ground Clearance	110 mm
Rake (Steering Head) (Deg)	30.2
Trail	135 mm
Wheelbase	1495 mm
Tires, Front Specifications	130/90B16 73H
Tires, Rear Specification	150/80B16 77H
Fuel capacity	7.9 l
Oil Capacity (W/Filter)	2.6 l
Weight, as Shipped	247 kg
Weight, in Running Order	252 kg

ENGINE

Engine	Air-cooled, Evolution^™
Bore	88.9 mm
Stroke	96.8 mm
Displacement	1202 cm³
Compression Ratio	10.01
Fuel System	Electronic Sequential Port Fuel Injection (ESPFI)
Exhaust	Black, staggered, shorty exhaust with dual mufflers

DRIVE TRAIN

Primary Drive (*Cert)	Chain, 34/46 ratio
Gear Ratio (Overall) 1^st (*Cert)	9.004
Gear Ratio (Overall) 2^nd (*Cert)	6.432
Gear Ratio (Overall) 3^rd (*Cert)	4.783
Gear Ratio (Overall) 4^th (*Cert)	3.965
Gear Ratio (Overall) 5^th (*Cert)	3.4

PERFORMANCE

Engine Torque Testing Method	EC 134/2014
Engine Torque (*Cert)	96 Nm
Engine Torque (RPM)	3500
Lean Angle, Right (Deg.)	27.1
Lean Angle, Left (Deg.)	27.1

CHASSIS

Wheels, Front Type	Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
Wheels, Rear Type	Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
Brakes, Caliper Type	Dual-piston front, Dual-piston rear

ELECTRIC

Lights (As per country regulation), Indicator Lamps	High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
Gauges	Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
