DESCRIPTION
A bare essentials bike with all the modern capabilities for the Touring purist. Built to make it your own.
DISCLAIMER
Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered. Availability may vary by market, please see your local dealer for details.
SPECIFICATION
DIMENSIONS
Length
2400 mm
Seat Height, Unladen
680 mm
Ground Clearance
120 mm
Rake (Steering Head) (Deg)
26
Trail
170 mm
Wheelbase
1625 mm
Tires, Front Specifications
BW 130/80B17 65H
Tires, Rear Specification
BW 180/65B16 81H
Fuel Capacity
22.7 l
Oil Capacity
4.9 l
Weight, as Shipped
354 kg
Weight, in Running Order
372 kg
Luggage Capacity - Volume
0.064 m3
ENGINE
Engine
Milwaukee-Eight™ 107
Bore
100 mm
Stroke
111 mm
Displacement
1746 cm3
Compression Ratio
10.0:1
Fuel System
Electronic Sequential Port Fuel Injection (ESPFI)
Exhaust
Chrome, 2-1-2 dual exhaust with tapered mufflers
DRIVE TRAIN
Primary Drive (*Cert)
Chain, 34/46 ratio
Gear Ratio (Overall) 1st (*Cert)
9.593
Gear Ratio (Overall) 2nd (*Cert)
6.65
Gear Ratio (Overall) 3rd (*Cert)
4.938
Gear Ratio (Overall) 4th (*Cert)
4
Gear Ratio (Overall) 5th (*Cert)
3.407
Gear Ratio (Overall) 6th (*Cert)
2.875
PERFORMANCE
Engine Torque Testing Method
EC 134/2014
Engine Torque (*Cert)
147 Nm
Engine Torque (RPM)
3250
Lean Angle, Right (Deg.)
31
Lean Angle, Left (Deg.)
29
CHASSIS
Wheels, Front Type
Impeller Cast Aluminum
Wheels, Rear Type
Brakes, Caliper Type
32 mm, 4-piston fixed front and rear
ELECTRIC
Lights (As per country regulation), Indicator Lamps
High beam, running lights, directional lights, low oil pressure, engine diagnostics, neutral, cruise control, accessory, battery, gear indication, security system, 6-speed, low fuel warning, ABS, miles to empty display, fog/aux lamp indicator
GAUGES
Gauges styled to complement each vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.
